Chiossi e Cavazzuti Dual 1200 - single belt Conveyor Dryer

$0.00 $0.00
SKU CC-1390052

Specifically designed to cure and dry DTG printing on fabrics.

IN STOCK IN MN - READY TO SHIP

The Tetris gamma is a new generation of conveyor dryers, built and designed with almost 40 years of experience for long lasting and high quality machines, proudly produced in Italy. Specifically designed to cure and dry DTG printing on fabrics, the massive advantage of these dryers is the high volume of forced air circulation.

The massive advantage of these dryers is the high volume of forced air circulation: this facilitates and accelerates the evaporation of water-based digital inks with unmatched results on the finished garment in medium-long drying process. Dries DTG prints from Epson SureColor F2100, Epson Surecolor F3070 Industrial Direct to Garment printer, Brother GTX pro, Kornit, Aeoon, and more

PDF Download

Installation PDF

The ACE 950 is the perfect match with an Epson SureColor F3070, Brother GTX Pro, KORNIT STORM 1000, or HEXA, which has an output of up to 170 light and 85 dark garments per hour.

Technical Data Ace 950 Dual 1200
Electrical requirements 400V 3phase (108V/230V 3 phase optional) 400V 3phase (108V/230V 3 phase optional)
Power consumption                                 14kW-20A 19kW-29A
Max temperature 356 F 356F
Exhaust specification 180 m³/h - Ø 150 mm  180 m³/h - Ø 150 mm
Tunnel length                                 78.75" 78.75"
Belt Width  37.4" 47.25"
Production (light-dark)  160-100 pieces per hour 240-160 pieces per hour
Dimension (LxWxH)  149.6"x49.2"x88.6" 161.4"x 59.02" x 88.6"
Shipping Weight                                 1433 lbs 1719 lbs.
